The 5TB-Magnetic separator it can processing : sesame, beans, soya beans, kidney beans, rice, seeds and different grains.
The Magnetic Separator will remove the metals and magnetic clods and soils from the material, when the grains or beans or sesame feed in the magnetic separator, the belt conveyor will transport to the strong magnetic roller, All the material will be thrown out in the end of the conveyor, because the different strength of magnetism of metal and magnetic clods and soils, their running route will change, then it will separate from the good grains and beans and sesame .
That’s how the clod remover machine working .
Magnetic separator consists of Bucket Elevator, Belt conveyor, Grain Exits., Frequency converter, brand motors, Japan Bearing
Low speed no broken slope elevator: Loading grains and seeds and beans to the magnetic separator without any broken
Stainless steel surface : Used for food processing
Frequency converter :Adjusting the vibrating frequency for suitable different grains, beans, sesames and rice
The iron in soil is not free, elemental iron, but rather iron-containing compounds. Many iron compounds are ferromagnetic, thus soil possesses a degree of ferromagnetism. Therefore, magnetic separators remove soil clods and impurities based on this magnetic property. Since soil’s ferromagnetism is very weak, ordinary magnets have difficulty exerting a significant attraction on it. Firstly, the magnetic separator must utilize a specialized structure to further strengthen its magnetic force. Secondly, it must effectively utilize this weak attraction, amplifying its effect with minimal effort to ensure that no soil clods escape the separator.
The process of cleaning wheat with a magnetic separator: Wheat is fed into the feeding hopper, then enters the grain bin via the elevator and three-way valve. The wheat is then dispersed evenly on the conveyor belt. Under the transport of the conveyor belt, the wheat passes through two rows of filter magnets and magnetic rollers and is then flattened and scattered (to remove strongly magnetic iron impurities from the wheat and prevent iron impurities from contacting the magnetic rollers and damaging the conveyor belt), forming a flat surface. Since the soil particles contain ferromagnetic substances and are magnetic, their trajectory will change after passing through the magnetic rollers. Therefore, the material can be separated from the soil particles by the diversion plate, and finally enter the grain outlet and soil outlet of the grain bin respectively.
Advantage
● Easy to operate with high performance .
● High Purity :99.9% purity especially for cleaning sesame and mung beans
● High quality motor for seeds cleaning machine, high quality Japan bearing .
● 5-10 Ton per hour cleaning capacity for cleaning different seeds and clean grains.
● Non broken low speed slope bucket elevator without any damage for the seeds and grains.
The magnetic separator will be used in the sesame and beans processing plant for get more high purity of the sesame and beans and grains .
As we know, when harvesting from farmland and ground, the sesame and beans will be mixed with soil and clods . Because of the weight, size and shape of the soil is the same as that of the sesame and beans, it is very difficult to remove with a simple cleaner machine, so we need to use a professional magnetic separator. To clean up the soil in the sesame and beans and soya beans and kidney beans .
In fact, our machine can not only clean various beans, grains, seeds, etc. It can also clean a lot of herbs, such as cumin, anise, fennel, thyme leaves, hibiscus flower, etc. It can effectively remove impurities and retain the parts that customers want to keep.
If customers have special requirements, they can put them forward to us. In this way, we can make special designs according to customer requirements.
Adhere to quality and pursue excellence. We at TAOBO Machinery Company will uphold the principle of customer first and provide customers with the best quality machines.
