10C Air screen cleaner
Introduction
The seed cleaner and grains cleaner it can remove the dust and light impurities by vertical air screen , Then vibrating boxes can remove the big and small impurities , and Grains and seeds can be separated big ,medium and small size by different sieves . and it can remove the stones .
Features
● The seed and grains air screen cleaner consists of dust collector , Vertical screen, vibration box sieves and Non-broken low speed bucket elevator.
● It is widely used in seed processing and grains processing plant and Pulses processing plant as the Pre-cleaner.
● The material can be classified into big, medium and small particles with different layers of sieves ( Stainless steel sieves ).
Advantage
● High Purity :98%-99% purity
● 5-10Ton per hour cleaning capacity for cleaning different seeds and clean grains.
● Non broken low speed bucket elevator without any damage for the seeds and grains.
● High quality motor for seeds cleaning machine ,high quality Japan bearing .
● Easy to operate with high performance .
Details show
Japan bearing
Brand motor
stainless steel sieve
Technical specifications
|
Name |
Model |
Size of sieves（mm) |
Layer |
Capacity (T/H) |
Weight（T） |
Oversize L*W*H（MM) |
Power(KW) |
Voltage |
|
Air screen cleaner |
5TB-5B |
1000*2000 |
Three |
5 |
1.5 |
4500*1800*3400 |
7.5 |
380V 50HZ |
|
5TB-5C |
1000*2000 |
Four |
5 |
1.53 |
4500*1800*3400 |
7.5 |
380V 50HZ |
|
|
5TB-7.5B |
1250*2400 |
Three |
7.5 |
1.8 |
5100*2050*3450 |
8.5 |
380V 50HZ |
|
|
5TB-7.5C |
1250*2400 |
Four |
7.5 |
1.83 |
5100*2050*3450 |
8.5 |
380V 50HZ |
|
|
5TB-10C |
1500*2400 |
Four |
10 |
2.0 |
5100*2300*3600 |
10.5 |
380V 50HZ |
|
|
5TB-10D |
1500*2400 |
Five |
10 |
2.2 |
5100*2300*3600 |
10.5 |
380V 50HZ |
Questions from clients
What material the seed cleaner can clean ?
It can clean most of seeds and grains,Beans and so on,it can improve the purity of agro products,Most Agro exporters are using our cleaner for satisfied with the goverment customer for exporting .
What is the capacity for the cleaner ?
Normally it can upto 5-10tons per hour cleaning seeds and grains . Generally it depends on what material you want to clean,Because different material the processing effency it is difference .
